Key attributes
| Category | Parameter | TechnicalSpecification | Remarks |
| Basic Parameters | Machine Model | 405 | |
| Power Supply Voltage | 220V/380V/Other voltages customizable | ||
| Rated Power | 2.2KW | Optional | |
| Working Air Pressure | 0.6-0.8MPa | ||
| Saw Blade Size | 40525.43.0*120 (mm) | (DiameterInner HoleThickness*Tooth Count) | |
| Dimension & Weight | Equipment Size | 8007501100mm | Equipped with 1m Aluminum Fence |
| Equipment Weight | 150KG | ||
| Wooden Case Size | 8608101200mm | ||
| Wooden Case Weight | 1650KG | ||
| Cutting Capacity | Applicable Materials | Aluminum, Wood, PVC, etc. | Other materials expandable |
| Cutting Angles | 45°, 90° | ||
| Maximum Cutting Thickness | 120mm | Customizable | |
| Maximum Cutting Stroke | 100mm | Customizable | |
| Mechanical Performance | Cutting Accuracy | ±0.15mm | Adjustable |
| Cutting Speed | 10-15 times/minute | Adjustable | |
| Blade Material | Titanium Alloy | Titanium alloy saw blade is recommended for high wear resistance requirements |
Ffeatures at a glance
Feature
1. The machine is used for cutting of aluminum and upvc profile and wood
2. Imported carbides blade is of accurate processing and high endurance. 3.This 45 90 degree corner notching machine is suitable for cutting and beveling picture frames, photo frames, wooden strips, furniture, plastic strips, aluminum profiles and door frames. It can make the movable table work very smoothly during the cutting process.
